Filling volume

300-5000ml

Filling Heads

1—12

Capacity

2000-3500 bottles/hour

Control system

PLC+ Touch screen

Precision

±0.5-1.0%

Bottle height

100-250 mm (adjustable)

Voltage

AC220V or AC 380V

Power

2.0-3.5Kw.

Pneumatic

0.35cbm/min, 0.6-0.8Mpa

Dimension

L550*W85*H190cm

G.W.

900-1200Kg.

Auxilary equipments

Auto bottles feeder, auto capping machine, auto induction sealing machine, auto labelling machine, shrink labelling machine, ink-jet printer, auto carton packing machine,etc.

Function

This automatic filling machine, adopts plunger pump filling, Equiped with PLC and touch screen, easy to operate. Main pneumatic parts and the electronics are famous brand from Japan or German. The body and the parts contacting with product is stainless steel, clean and sanitary comply with GMP standard. The filling volume and speed can be adjusted easily, and filling nozzles could be changed according to actual needs. This filling line can be used to fill various liquid products of medicines, foods, drinks, chemicals, detergents, pesticide, etc. e.x. shampoo, detergent, lotion, juice, wine, vinegar, etc.
